E115AET (2003)
FUEL 3
Diagram: FUEL 3
Parts List
Reference
Description
Price
1
6Y2−24306−53
AP FOR TUNA
Fuel pipe comp. 1
Loading…
↗
2
6E5−24305−04
Fuel pipe joint comp. 2
Loading…
↗
3
93210−08287
O-ring (655)
Loading…
↗
4
6Y2−24305−04
Fuel pipe joint comp. 2
Loading…
↗
6
90445−13M01
Hose (l2050)
Loading…
↗
7
6E5−24351−51
Band 1
Loading…
↗
8
90445−13M00
Hose (l850)
Loading…
↗
9
6Y2−24360−52
Primer pump assembly
Loading…
↗
