FL150AET (2008)
FUEL INJECTION PUMP 2
Diagram: FUEL INJECTION PUMP 2
Parts List
Reference
Description
Price
1
63P1414900
Pipe
Loading…
↗
2
63P1397100
Pipe, fuel 1 (with filter)
Loading…
↗
3
63P1354600
Hose 2
Loading…
↗
4
63P1354500
Hose 1
Loading…
↗
5
63P1353210
Hose, vacuum sensing 3
Loading…
↗
6
63P1316000
Delivery pipe assembly 1
Loading…
↗
7
63P1422500
Cap
Loading…
↗
8
63P1397420
Pipe, fuel 4
Loading…
↗
9
63P1397600
Pipe, fuel 6
Loading…
↗
10
68V2411M00
Clip
Loading…
↗
11
63P2431700
Pipe 7
Loading…
↗
12
63P2247B00
Hose 2
Loading…
↗
13
68V2451900
Clip
Loading…
↗
14
63P2432500
Pipe 14
Loading…
↗
15
68V1357700
Clip
Loading…
↗
16
69J2450110
Filter, fuel
Loading…
↗
17
69J2459910
Cap
Loading…
↗
18
63P1397500
Pipe, fuel 5
Loading…
↗
19
6P21375800
Pipe, joint
Loading…
↗
20
68V2481H00
Clamp
Loading…
↗
21
63P2417H00
Clamp 1
Loading…
↗
22
63P2417J00
Clamp 2
Loading…
↗
