25BMH (2003)
GENERATOR
Diagram: GENERATOR
Parts List
Reference
Description
Price
1
61T−85550−10
Rotor assembly
Loading…
↗
2
69P−85560−00
Base assembly
Loading…
↗
3
69P−85541−09
Coil, charge
Loading…
↗
4
61N−81313−09
Coil, lighting 1
Loading…
↗
5
61N−85543−09
Coil, pulser
Loading…
↗
6
61N−85543−19
Coil, pulser
Loading…
↗
7
6E9−81328−70
Clamp
Loading…
↗
8
97802−04006
Screw, pan head(3xp)
Loading…
↗
9
6E9−85516−70
Grommet
Loading…
↗
10
69P−85561−00
Base, magneto
Loading…
↗
11
97607−04112
Screw, pan head
Loading…
↗
12
97607−06125
Screw, pan head (76t)
Loading…
↗
13
61N−85537−00
Cover
Loading…
↗
14
90280−05015
Key, woodruff
Loading…
↗
15
90179−16M05
Nut (689)
Loading…
↗
16
90201−16M44
Washer (689)
Loading…
↗
17
676−41611−00
Retainer, magneto base 1
Loading…
↗
18
676−41613−00
Plate, base friction
Loading…
↗
19
97880−05012
Screw,pan head (646)
Loading…
↗
20
92990−05600
Washer, plain (646)
Loading…
↗
21
689−41612−01
Retainer, magneto base
Loading…
↗
22
97880−06010
Screw pan head
Loading…
↗
