FL350AET (2017)
INTAKE 1
Diagram: INTAKE 1
Parts List
Reference
Description
Price
1
9587508035
Bolt, flange
Loading…
↗
2
9953010114
Pin, dowel(3vd)
Loading…
↗
3
6AW1378200
Stay
Loading…
↗
4
9759506512
Bolt, hexagon w/w deep recess
Loading…
↗
5
9046409023
Clamp
Loading…
↗
6
6AW1364110
Manifold 1
Loading…
↗
7
6AW1364500
Gasket, manifold 1
Loading…
↗
8
6AW1364600
Gasket, manifold 2
Loading…
↗
9
9011908022
Bolt, with washer
Loading…
↗
10
9011906MA6
Bolt, with washer
Loading…
↗
11
9046417006
Clamp
Loading…
↗
17
6P22417000
Canister assembly
Loading…
↗
18
6AW2134X10
Bracket, canister
Loading…
↗
19
9589506016
Bolt, flange deep recess
Loading…
↗
20
69J2134X00
Bracket, canister
Loading…
↗
21
9011906M17
Bolt, with washer
Loading…
↗
22
9048010M23
Grommet(6k7)
Loading…
↗
23
9038706289
Collar
Loading…
↗
24
69J2419A01
Holder
Loading…
↗
25
9759506516
Bolt, with washer(6r6)
Loading…
↗
26
9011906269
Bolt, with washer
Loading…
↗
27
6AW2441900
Brkt., separator
Loading…
↗
29
9038706276
Collar
Loading…
↗
30
9011606046
Bolt, stud
Loading…
↗
31
9017906M28
Nut(63v)
Loading…
↗
