Yamaha Outboard Parts - Intake - 4ACMH (1988) | Flood Marine

Diagram: Intake

Diagram

Parts List

Reference
Description
Price


1
6E0136100000
Reed valve assembly
Loading…

↗
2
6E0W00040000
Reed set
Loading…

↗
3
6E0136210000
Gasket, valve seat
Loading…

↗
4
9010506M1400
Bolt (6e0)
Loading…

↗
5
6E0143010200
Carburetor assembly 1
Loading…

↗
6
6E0141800000
Float chamber assembly
Loading…

↗
7
6E0143840000
Gasket, float chamber
Loading…

↗
8
985800401600
Screw, panhead (796)
Loading…

↗
9
677143830000
Screw, drain
Loading…

↗
10
6A1143980000
Gasket
Loading…

↗
11
6E7143850000
Float
Loading…

↗
12
647143861000
Pin, float
Loading…

↗
13
6E0143410100
Nozzle, main
Loading…

↗
14
648143434000
Jet, main (#80)
Loading…

↗
15
6G8143920000
Valve, needle
Loading…

↗
16
6E0141570000
Cover, plate
Loading…

↗
17
6E0142270000
Gasket
Loading…

↗
18
985800400800
Screw, pan head (713)
Loading…

↗
19
647143230000
Screw, air adjusting
Loading…

↗
20
646142120100
Spring, pilot adjusting
Loading…

↗
21
648143210000
Screw, pan head(ga5)
Loading…

↗
22
648143422300
Jet, pilot (#46)
Loading…

↗
23
647143260000
Screw, guide
Loading…

↗
24
985800402000
Screw, pan head (7h3)
Loading…

↗
25
6E0244130000
Cover, pump
Loading…

↗
26
6E0244710000
Diaphragm
Loading…

↗
27
6E0244350000
Gasket, cover pump
Loading…

↗
28
6E0244120000
Body, pump
Loading…

↗
29
6E0244230000
Spring
Loading…

↗
30
6E0143460000
Plate
Loading…

↗
31
6E0244110000
Diaphragm
Loading…

↗
32
6E0244340000
Gasket, body pump
Loading…

↗
33
6E014198A000
Gasket
Loading…

↗
34
953030670000
Nut
Loading…

↗
35
929900660000
Washer, plain (646)
Loading…

↗
36
6E0144170000
Cover 1
Loading…

↗
37
6E0144180000
Cover 2
Loading…

↗
38
985030502500
Screw, panhead (a93)
Loading…

↗
39
929900560000
Washer, plain (646)
Loading…

↗
40
977804072000
Ybs81-420 screw,0.head tapping
Loading…

↗
41
6E0412560000
Rod, choke link
Loading…

↗
42
6E0412710100
Knob, choke
Loading…

↗
43
6E0412720000
Knob, choke 2
Loading…

↗
44
9020212M1600
Washer, plate (6e0)
Loading…

↗
45
661412620200
Joint, choke lever
Loading…

↗
46
956210632500
Bolt, stud(6e0)
Loading…

↗
47
9011606M0800
Bolt, stud (689)
Loading…

↗
