6DEM (1990)
Intake
Diagram: Intake
Parts List
Reference
Description
Price
1
6G1136100100
Reed valve assembly
Loading…
↗
2
6G1W00040000
Reed set
Loading…
↗
3
6G1136210000
Gasket, valve seat
Loading…
↗
4
6G1136410094
Manifold, intake 1
Loading…
↗
5
6G1136450000
Gasket, intake manifold
Loading…
↗
6
6G114198A100
Gasket
Loading…
↗
7
958950608500
Bolt, flange(6g1)
Loading…
↗
8
6G1144170000
Cover set
Loading…
↗
9
6M8E44180000
Cover 2
Loading…
↗
10
9038706M7000
Collar (6h5)
Loading…
↗
11
977805051400
Screw, panhead tapping (682)
Loading…
↗
12
6G1412560000
Rod, choke link
Loading…
↗
13
6G1412710000
Knob, choke 1
Loading…
↗
