F4AMH (2006)
LOWER CASING & DRIVE 1
Diagram: LOWER CASING & DRIVE 1
Parts List
Reference
Description
Price
1
68DG5300114D
L (22.1")
Lower Unit assembly
Loading…
↗
1
68DG5300014D
S (17.1")
Lower Unit assembly
Loading…
↗
2
68DG5311004D
Casing, lower
Loading…
↗
3
6E04531709
Bushing
Loading…
↗
4
6E04531609
Bushing
Loading…
↗
5
9310110M14
Oil seal
Loading…
↗
6
93306004YH
Bearing (7k2)
Loading…
↗
7
9043008020
Gasket
Loading…
↗
8
9034008002
Plug, straight screw
Loading…
↗
9
68DG532100
Plate
Loading…
↗
10
6L24414700
Boot, shift rod
Loading…
↗
11
68DG5315A0
Packing, lower cas
Loading…
↗
12
9709506025
Bolt
Loading…
↗
13
9299506600
Washer, plain (646)
Loading…
↗
14
68DG5361004D
Cap, lower casing
Loading…
↗
16
9310113M12
Oil seal
Loading…
↗
17
9321048214
O-ring
Loading…
↗
18
9589506016
Bolt, flange deep recess
Loading…
↗
19
68DG431101
Housing water pump
Loading…
↗
20
68DG4315A0
Gasket, water pump
Loading…
↗
21
6E04432202
Insert, cartridge
Loading…
↗
22
6E04432300
Outer plate, cartridge
Loading…
↗
23
67D4436600
Damper, water seal 2
Loading…
↗
24
6E04435200
Impeller
Loading…
↗
25
9360409066
Pin, dowel
Loading…
↗
26
9709506045
Bolt, hexagon
Loading…
↗
27
9360418080
Pin. dowel. (647)
Loading…
↗
28
68DG432800
Plate
Loading…
↗
29
68DG551100
S (17.1")
Shaft, drive
Loading…
↗
29
68DG551110
L (22.1")
Shaft, drive
Loading…
↗
30
9046708M01
Clip (6e0)
Loading…
↗
31
6E04555100
Pinion (13t)
Loading…
↗
32
9900106600
Circlip(53l)
Loading…
↗
33
9020111M49
Washer, plate (6e0)
Loading…
↗
34
67D4556000
Gear
Loading…
↗
35
67D4557000
Gear
Loading…
↗
36
67D4557600
Washer, thrust 2
Loading…
↗
37
67D4563101
Clutch, dog
Loading…
↗
38
9050110064
Spring, compression 6164563600
Loading…
↗
39
67D4563500
Plunger, shift
Loading…
↗
40
68DG561110
Shaft, propeller
Loading…
↗
41
68DG415000
S (17.1")
Shift cam assembly
Loading…
↗
41
68DG415010
L (22.1")
Shift cam assembly
Loading…
↗
