F225XCB (2022)
LOWER CASING & DRIVE 2
Diagram: LOWER CASING & DRIVE 2
Parts List
Reference
Description
Price
1
6AW4436501
Damper, water seal 1
Loading…
↗
2
6AW4436601
Damper, water seal 2
Loading…
↗
3
6CE4436100
Tube, water 1
Loading…
↗
4
9360816M16
Pin, dowel(6t4)
Loading…
↗
5
9011910024
Bolt, with washer
Loading…
↗
6
97E7510570
Bolt, hexagon w/w deep recess
Loading…
↗
7
6KA4521400
Cover, water inlet 1
Loading…
↗
8
6KA4521500
Cover, water inlet 2
Loading…
↗
9
9011005039
Bolt, hexagon socket head
Loading…
↗
10
6CE4522400
Cover, water inlet 3
Loading…
↗
11
6CE4522500
Cover, water inlet 4
Loading…
↗
12
9018505002
Nut nylon (sus)(ex4)
Loading…
↗
14
6KA4525400
Cover, outlet 1
Loading…
↗
15
6KA4525500
Cover, outlet 2
Loading…
↗
17
9138005020
Bolt,socket
Loading…
↗
18
6CE4537300
Anode
Loading…
↗
19
9010510M00
Bolt, hexagon (663)
Loading…
↗
20
69J4598700
Spacer 1
Loading…
↗
21
6884599701
Spacer 2
Loading…
↗
22
9299018200
Washer (6e5)
Loading…
↗
23
9017118M04
Nut, castle (6e5)
Loading…
↗
24
9149040030
Pin, cotter (663)
Loading…
↗
25
6KA4597000
UR
Propeller (3X15-1/4"X18"-T)
Loading…
↗
25
6KA4597200
UR
Propeller (ss 3x15-1/4 x19 -t)
Loading…
↗
25
6KA4597400
UR
Propeller (ss 3x15 x20 -t)
Loading…
↗
25
6KA4597600
UR
Propeller (ss 3x15 x21 -t)
Loading…
↗
26
6CE45C8110
Damper rubber, propeller 1
Loading…
↗
