F80DET (2017)
LOWER CASING & DRIVE 2
Diagram: LOWER CASING & DRIVE 2
Parts List
Reference
Description
Price
1
6E54436600
Damper, water seal 2
Loading…
↗
2
9044016001
L(20.3")
Pipe
Loading…
↗
2
9044016002
X(25.3")
Pipe
Loading…
↗
3
6EK4436501
Damper, water seal 1
Loading…
↗
4
6EK4437900
Guide, water tube
Loading…
↗
5
9360812M05
Pin, dowel b (6e5)
Loading…
↗
6
9759510545
Bolt, hexagon w/w deep recess
Loading…
↗
7
9011910M89
Bolt, with washer
Loading…
↗
8
6884521402
Cover, water inlet
Loading…
↗
9
6884521502
Cover, water inlet
Loading…
↗
10
9015205M07
Screw, countersunk
Loading…
↗
11
9018505002
Nut nylon (sus)(ex4)
Loading…
↗
12
6E54537101
Trim tab
Loading…
↗
13
9010510M00
Bolt, hexagon (663)
Loading…
↗
14
63P4598700
Spacer 1
Loading…
↗
15
6884599701
Spacer 2
Loading…
↗
16
9299018200
Washer (6e5)
Loading…
↗
17
9017118M04
Nut, castle (6e5)
Loading…
↗
18
9149040030
Pin, cotter (663)
Loading…
↗
19
6E54594501
Propeller (3x13-1/4x17-k)
Loading…
↗
20
6FP4594700
UR SDS PROP.
Propeller (al 3x13-1/8 x17 -k)
Loading…
↗
20
6FP4594900
UR SDS PROP.
Propeller (al 3x13 x18 -k)
Loading…
↗
20
6FP4594500
UR SDS PROP.
Propeller (al 3x13-1/4 x16 -k)
Loading…
↗
20
6FP4594300
UR SDS PROP.
Propeller (al 3x13-1/2 x15 -k)
Loading…
↗
20
6FP4594100
UR SDS PROP.
Propeller (al 3x13-5/8 x14 -k)
Loading…
↗
21
6EK4598200
Bush, propeller
Loading…
↗
22
6EK45C8209
Damper rubber, propeller 2
Loading…
↗
