25BMH (2002)
LOWER CASING. DRIVE 1
Diagram: LOWER CASING. DRIVE 1
Parts List
Reference
Description
Price
1
69P45300104D
L
Lower unit assembly
Loading…
↗
1
69P45300004D
S
Lower unit assembly
Loading…
↗
2
61N--45311--02--4D
Casing, lower
Loading…
↗
3
93332--000W5
Bearing(61n)
Loading…
↗
4
61N--45587--00--10
UR
Shim (t:1.0mm)
Loading…
↗
4
61N--45587--00--11
UR
Shim (t:1.1mm)
Loading…
↗
4
61N--45587--00--12
UR
Shim (t:1.2mm)
Loading…
↗
4
61N--45587--00--13
UR
Shim (t:1.3mm)
Loading…
↗
4
61N--45587--00--14
UR
Shim (t:1.4mm)
Loading…
↗
4
61N--45587--00--15
UR
Shim (t:1.5mm)
Loading…
↗
4
61N--45587--00--16
UR
Shim (t:1.6mm)
Loading…
↗
4
61N--45587--00--07
UR
Shim (t:0.70mm)
Loading…
↗
5
61N--45536--00
Sleeve, drive shaft
Loading…
↗
6
93315--220V7
Bearing, cylindrical(6j8)
Loading…
↗
7
61N--44362--00
S
Tube, water
Loading…
↗
7
61N--44362--10
L
Tube, water
Loading…
↗
8
93210--22164
S
O-ring
Loading…
↗
9
93210--26130
S
O-ring
Loading…
↗
10
69P4431100
Housing, water pump
Loading…
↗
11
6L2--44367--00
Damper, water seal 3
Loading…
↗
12
69P--44322--00
FOR STD
Insert, cartridge
Loading…
↗
12
69P--44322--40
FOR CHROMATE
Insert, cartridge
Loading…
↗
13
6H4--44352--02
Impeller
Loading…
↗
14
93210--45161
O-ring
Loading…
↗
15
61N--44323--00
FOR STD
Outer plate, cartridge
Loading…
↗
15
61N--44323--40
FOR CHROMATE
Outer plate, cartridge
Loading…
↗
16
97095--06040
Bolt (682)
Loading…
↗
17
92995--06600
Washer, plain (646)
Loading…
↗
18
65W--44328--11
L
Plate
Loading…
↗
19
61N--44176--00
Bracket
Loading…
↗
20
61N--45321--00
Plate
Loading…
↗
21
93210--06ME6
O-ring
Loading…
↗
22
97095--06025
Bolt
Loading…
↗
24
61N--45331--00--5B
Housing, bearing
Loading…
↗
25
93604--10M03
Pin, dowel (688)
Loading…
↗
26
61N--45127--00
Seal
Loading…
↗
27
61N--45315--00
Packing, lower casing
Loading…
↗
28
93101--22067
Oil seal (22x36x6-663)
Loading…
↗
29
90340--08002
Plug, straight screw
Loading…
↗
30
90430--08020
Gasket
Loading…
↗
31
61N--45251--01
Anode
Loading…
↗
32
95895--06035
Bolt, flange(4nx)
Loading…
↗
33
92990--06300
Washer, tooth
Loading…
↗
34
688--45341--10
Plug, drain
Loading…
↗
36
61N--45510--00
S
Drive shaft assembly
Loading…
↗
36
61N--45510--10
L
Drive shaft assembly
Loading…
↗
37
90280--03M03
Key, woodruff (697)
Loading…
↗
38
61N--45551--00
Pinion
Loading…
↗
39
90179--10M14
Nut(6j8)
Loading…
↗
40
93332--00005
Brg,cyl-cal roller 0.19g nt
Loading…
↗
41
6L2--45567--00--10
UR
Shim (t:1.0mm)
Loading…
↗
41
6L2--45567--00--11
UR
Shim (t:1.1mm)
Loading…
↗
41
6L2--45567--00--12
UR
Shim (t:1.2mm)
Loading…
↗
41
6L2--45567--00--13
UR
Shim (t:1.3mm)
Loading…
↗
41
6L2--45567--00--14
UR
Shim (t:1.4mm)
Loading…
↗
42
61N--45560--00
Gear
Loading…
↗
43
6L2--45611--00
Shaft, propeller
Loading…
↗
44
648--45635--00
Plunger,shift
Loading…
↗
45
664--45631--02
Clutch, dog
Loading…
↗
46
90250--05010
Pin straight 648456320000
Loading…
↗
47
648--45633--00
Ring, cross pin
Loading…
↗
48
90501--10065
Spring compression648456360000
Loading…
↗
49
90201--20417
Washer, plate(663)
Loading…
↗
50
61N--45571--00
Gear
Loading…
↗
51
6L2--45577--00--10
UR
Shim (t:1.0mm)
Loading…
↗
51
6L2--45577--00--11
UR
Shim (t:1.1mm)
Loading…
↗
51
6L2--45577--00--12
UR
Shim (t:1.2mm)
Loading…
↗
51
6L2--45577--00--13
UR
Shim (t:1.3mm)
Loading…
↗
52
61N--45361--01--4D
Cap, lower casing
Loading…
↗
53
93306--00612
Bearing(2hr)
Loading…
↗
54
93210--64ME7
O-ring
Loading…
↗
55
93315--22004
Brg,cyl-cal roller 21g nt
Loading…
↗
56
93101--20M07
Oil seal
Loading…
↗
57
93210--65M50
O-ring
Loading…
↗
58
97075--06020
Bolt(7u8)
Loading…
↗
60
61N--44150--00
S
Shift cam assembly
Loading…
↗
60
61N--44150--10
L
Shift cam assembly
Loading…
↗
