FT50CET (2003)
LOWER CASING. DRIVE 3 (FT50C)
Diagram: LOWER CASING. DRIVE 3 (FT50C)
Parts List
Reference
Description
Price
1
64J−45300−30−4D
L
Lower unit assembly
Loading…
↗
2
67F−45301−00−4D
Casing, lower
Loading…
↗
3
93315−325W4
Bearing
Loading…
↗
4
688−45536−01
Sleeve, drive shaft
Loading…
↗
5
688−45587−01−12
UR
Shim (t:0.12mm)
Loading…
↗
5
688−45587−01−15
UR
Shim (t:0.15mm)
Loading…
↗
5
688−45587−01−18
UR
Shim (t:0.18mm)
Loading…
↗
5
688−45587−01−30
UR
Shim (t:0.30mm)
Loading…
↗
5
688−45587−01−40
UR
Shim (t:0.40mm)
Loading…
↗
5
688−45587−01−50
UR
Shim (t:0.50mm)
Loading…
↗
5
688−45587−01−10
UR
Shim (t:0.10mm)
Loading…
↗
6
93332−000U3
Brg,tapered roller 50mm (688)
Loading…
↗
7
688−45567−01−10
UR
Shim (t:0.10mm)
Loading…
↗
7
688−45567−01−50
UR
Shim (t:0.50mm)
Loading…
↗
7
688−45567−01−40
UR
Shim (t:0.40mm)
Loading…
↗
7
688−45567−01−30
UR
Shim (t:0.30mm)
Loading…
↗
7
688−45567−01−18
UR
Shim (t:0.18mm)
Loading…
↗
7
688−45567−01−15
UR
Shim (t:0.15mm)
Loading…
↗
7
688−45567−01−12
UR
Shim (t:0.12mm)
Loading…
↗
8
93332−000UD
Bearing
Loading…
↗
9
90340−08002
Plug, straight screw
Loading…
↗
10
688−45341−10
Plug, drain
Loading…
↗
11
90430−08020
Gasket
Loading…
↗
12
688−45321−00
Plate
Loading…
↗
13
93210−49046
O-ring (620)
Loading…
↗
14
93106−09014
Oil seal
Loading…
↗
15
97095−06016
Bolt, hexagon deep recess
Loading…
↗
16
92995−06600
Washer, plain (646)
Loading…
↗
17
6E5−45378−00
Nipple, hose
Loading…
↗
18
90445−07M31
L
Hose (l200)
Loading…
↗
19
6E5−83558−10
End, nipple
Loading…
↗
20
90465−11M10
Clamp
Loading…
↗
21
6H3−44311−00
Housing, water pump 1
Loading…
↗
22
663−44322−00
Insert, cartridge
Loading…
↗
23
6H3−44315−A0
Gasket,water pump 1
Loading…
↗
24
663−44366−00
Damper, water seal 2
Loading…
↗
25
6H3−44352−00
Impellar
Loading…
↗
26
90280−03M03
Key, woodruff (697)
Loading…
↗
27
6H3−44341−00−94
Housing, water pump set
Loading…
↗
28
93101−23070
Oil seal (663)
Loading…
↗
29
93210−46044
O-ring
Loading…
↗
30
688−44316−A0
Gasket,water pump 2
Loading…
↗
31
6H3−44323−00
Outer plate, cartridge
Loading…
↗
32
6H3−44324−A0
Gasket,cartridge 0ut,plate
Loading…
↗
33
93604−10M03
Pin, dowel (688)
Loading…
↗
34
90119−08M33
Bolt, with washer(6b0)
Loading…
↗
35
90119−08M14
Bolt, with washer
Loading…
↗
36
64J−45501−30
L
Drive shaft comp. (l, d: 18mm)
Loading…
↗
37
64J−45551−00
Pinion
Loading…
↗
38
90170−16M01
Nut, hexagon (688)
Loading…
↗
39
64J−45560−00
Gear
Loading…
↗
40
93317−322V0
Bearing
Loading…
↗
41
67F−45611−00
Shaft, propeller
Loading…
↗
42
67F−45631−00
Clutch, dog
Loading…
↗
43
67F−45634−00
Slide, shift
Loading…
↗
44
6H1−45668−00
Shaft, free 1
Loading…
↗
45
6H1−45635−00
Plunger, shift
Loading…
↗
46
90501−12M48
Spring (6h1)
Loading…
↗
47
90201−03313
Washer, plate 8077743700
Loading…
↗
48
93503−16003
Ball
Loading…
↗
49
90183−02M03
Nut, spring (6h1)
Loading…
↗
50
90250−07M02
Pin, straight (688)
Loading…
↗
51
688−45633−00
Ping, cross pin
Loading…
↗
52
93210−07003
O-ring (11m)
Loading…
↗
53
99001−08600
Circlip(2r6)
Loading…
↗
54
67F−45571−00
Gear
Loading…
↗
55
67F−45331−00−94
Housing, bearing
Loading…
↗
56
93306−207U0
Brg,r-b 6207 72mm 280g (688)
Loading…
↗
57
67F−45576−00
Washer, thrust 2
Loading…
↗
58
93210−86M39
O-ring (6e5)
Loading…
↗
59
93317−325U0
Brg,needle
Loading…
↗
60
93101−25M03
Oil seal
Loading…
↗
61
90282−04010
Key, strait(663)
Loading…
↗
62
688−45383−02
Washer, claw
Loading…
↗
63
688−45384−02
Nut
Loading…
↗
64
64J−44150−00
Shift cam assembly
Loading…
↗
65
90201−25M05
Washer, plate
Loading…
↗
