50GETO (2002)
LOWER CASING. DRIVE 4
Diagram: LOWER CASING. DRIVE 4
Parts List
Reference
Description
Price
1
663--44367--00
Damper, water seal 3
Loading…
↗
2
6H34436110
L
Tube, water
Loading…
↗
3
90202--12060
Washer, plate(663)
Loading…
↗
4
90430--12072
Gasket
Loading…
↗
5
93606--12019
Pin, dowel (614)
Loading…
↗
6
97075--10040
Bolt, hexagon deep recess
Loading…
↗
7
92990--10100
Ybs67-10 washer, spring
Loading…
↗
8
92990--10600
Washer, plate
Loading…
↗
9
90119--08M84
Bolt, with washer
Loading…
↗
10
688--45214--02
Cover, water inlet
Loading…
↗
11
688--45215--02
Cover, water inlet
Loading…
↗
12
9015205M05
Screw, countersunk
Loading…
↗
13
90185--05002
Nut nylon (sus)(ex4)
Loading…
↗
14
6794537100
Tab trim
Loading…
↗
15
90105--10M67
Bolt, hexagon (663)
Loading…
↗
16
663--45987--02
Spacer
Loading…
↗
17
670--45997--02
Spacer
Loading…
↗
18
92990--16200
958-58204-00 washer,plain
Loading…
↗
19
90171--16011
Nut, castle (663)
Loading…
↗
20
91490--40025
Pin, cotter (663)
Loading…
↗
21
663--45945--02--EL
UR
Propeller (3x11-1/8"x13"-g)
Loading…
↗
21
663--45952--02--EL
UR
Propeller (3x11-3/8x12-g)
Loading…
↗
21
6H5--45943--00--EL
UR WITH LIP CUP
Propeller (3x10"x15"-g)
Loading…
↗
21
6H5--45958--00--EL
UR WITH LIP CUP
Propeller (3x10-1/4"x14"-g)
Loading…
↗
21
663--45930--00--98
UR
Propeller (3x10-1/4"x14"-g)
Loading…
↗
21
663--45976--00--98
UR
Propeller (3x10-1/4"x15"-g)
Loading…
↗
21
663--45978--00--98
UR
Propeller (3x10-1/4"x16"-g)
Loading…
↗
21
663--45970--60--98
UR
Propeller (3x11-3/4"x12"-g)
Loading…
↗
21
663--45972--60--98
UR
Propeller (3x12"x11"-g)
Loading…
↗
21
663--45974--60--98
UR
Propeller (3x11-1/2"x13"-g)
Loading…
↗
