Yamaha Outboard Parts - METER - E115AWH (2003) | Flood Marine

Diagram: METER

Diagram

Parts List

Reference
Description
Price


1
6Y5−83540−14 AP EXCEPT FOR TUNA
Tachometer assembly
Loading…

↗
2
6Y5−83517−00
Bulb (12v-1.7w)
Loading…

↗
3
6Y5−83536−10
Socket, meter
Loading…

↗
4
6Y5−83523−00
Damper
Loading…

↗
5
6Y5−83514−00
Plate, fitting
Loading…

↗
6
95380−05600
Nut, hexagon (663)
Loading…

↗
7
92990−05100
Ybs67-5 washer, spring
Loading…

↗
8
6Y5−83670−12 AP
Trim meter assembly.
Loading…

↗
9
6Y5−83518−00
Bulb (12v-1.7w) t6.5
Loading…

↗
10
6Y5−83536−00
Socket, meter
Loading…

↗
11
6Y5−83544−00
Plate, fitting
Loading…

↗
12
688−83664−00
Damper
Loading…

↗
13
6Y5−83553−00 AP
Wire, lead (l=2.5m)
Loading…

↗
14
1E6−82151−00
Fuse (10a)
Loading…

↗
15
6Y5−82117−00 AP EXCEPT FOR TUNA
Wire, lead
Loading…

↗
16
6R3−82553−70 AP 4P,7M
Extension, wire lead (for trim
Loading…

↗
