Yamaha Outboard Parts - METER 3 - Rigging - Meter (2025) | Flood Marine

Diagram: METER 3

Diagram

Parts List

Reference
Description
Price


1
6Y583570A3
Speedometer assembly
Loading…

↗
2
6Y88438300
Nut, ring
Loading…

↗
3
6Y587122S0
Cord assembly 1
Loading…

↗
4
6Y58355731
Tube
Loading…

↗
5
6Y58372800
Connector assembly
Loading…

↗
6
9046511M10
Clamp
Loading…

↗
7
6Y58355710
Tube (8m)
Loading…

↗
