Yamaha Outboard Parts - METER 5 - RIGGING - METER (2021) | Flood Marine

Diagram: METER 5

Diagram

Parts List

Reference
Description
Price


1
6Y5W008855
Digital fuel meter kit (single
Loading…

↗
2
6Y58350FB0
Fuel meter movement assembly
Loading…

↗
3
6Y88438300
Nut, ring
Loading…

↗
4
6Y587122S0
Cord assembly 1
Loading…

↗
5
6Y583553F1
Wire, lead
Loading…

↗
6
6Y58575202
Sender unit assembly, fuel meter
Loading…

↗
7
9015806003
Screw, wood
Loading…

↗
8
6Y58211700
Wire, lead
Loading…

↗
9
6Y585721F0 AP
Wire, lead
Loading…

↗
