Yamaha Outboard Parts - METER 5 - Rigging - Meter (2025) | Flood Marine

Diagram: METER 5

Diagram

Parts List

Reference

Description

Price

1

6Y5W008857

Digital Fuel Meter Kit(Single)

Loading…

2

6Y58350FB4

Fuel Meter Movement assembly

Loading…

3

6Y88438300

Loading…

4

6Y587122S1

Cord assembly 1

Loading…

5

6Y583553F2

Wire, Lead (L=8.0M)

Loading…

6

6Y58575202

Sender unit assembly, fuel meter

Loading…

7

9015806003

Loading…

8

6Y58211700

Loading…

9

6Y585721F0 AP

Loading…
