Yamaha Outboard Parts - OIL COOLER - ME422STIP2 (2013) | Flood Marine

Diagram: OIL COOLER

Diagram

Parts List

Reference
Description
Price


1
N601347000
Oil cooler assembly
Loading…

↗
2
N602149800
Bracket, oil cooler
Loading…

↗
3
9702708016
Bolt, hexagon
Loading…

↗
4
9290708600
Washer(6ta)
Loading…

↗
4
6
-
Loading…

↗
5
9702708020
Bolt, hexagon
Loading…

↗
7
N511258200
Joint, hose 2
Loading…

↗
8
N601257800
Hose 3
Loading…

↗
9
9045032008
Hose Clamp assembly
Loading…

↗
10
N601257900
Hose 4
Loading…

↗
