XF425NSA (2022)
OIL PAN
Diagram: OIL PAN
Parts List
Reference
Description
Price
1
6GR1531200
Gasket, oil pan
Loading…
↗
2
6GR1531B01
Oil pan 2
Loading…
↗
3
6GR1531C00
Gasket, oil pan 2
Loading…
↗
4
9011910074
Bolt, with washer
Loading…
↗
5
97E7510570
Bolt, hexagon w/w deep recess
Loading…
↗
6
9011910040
Bolt, with washer
Loading…
↗
7
9360612019
Pin, dowel (614)
Loading…
↗
8
6GR1531101
Oil pan
Loading…
↗
10
97E7510580
Bolt, hexagon w/w deep recess
Loading…
↗
12
6GR1535100
Plug, drain
Loading…
↗
13
9321034633
O-ring (21a)
Loading…
↗
14
9342036M01
Circlip (6a0)
Loading…
↗
15
6GR1341100
Strainer, oil
Loading…
↗
16
6GR1536200
Plug, oil level
Loading…
↗
17
6GR1537700
Guide, inlet
Loading…
↗
18
9321019MJ3
O-ring
Loading…
↗
19
95D9506016
Bolt, flange deep recess
Loading…
↗
20
6GR1531601
Damper 1
Loading…
↗
21
6GR1246A00
Cover 1
Loading…
↗
22
6G51241600
Valve, pressure control
Loading…
↗
23
90501200A2
Spring, compression
Loading…
↗
24
9048020M05
Grommet (688)
Loading…
↗
25
95D9506025
Bolt, flange deep recess
Loading…
↗
26
95D9506040
Bolt, flange deep recess
Loading…
↗
27
6EK12435A0
Gasket
Loading…
↗
28
6GR1243F00
Hose,3
Loading…
↗
29
6GR1257A01
Hose assembly 1
Loading…
↗
30
6GR1258100
Joint, hose 1
Loading…
↗
31
95D9506020
Bolt, flange deep recess
Loading…
↗
32
6GR4436601
Damper, water seal 2
Loading…
↗
33
97D9506012
Bolt, hexagon deep recess
Loading…
↗
34
6GR4515200
Cover, upper casing 2
Loading…
↗
35
9046466001
Clamp
Loading…
↗
