F15AEP (2002)
OIL PUMP
Diagram: OIL PUMP
Parts List
Reference
Description
Price
1
93102−18M21
Oil seal (6g8)
Loading…
↗
2
66M−12171−10
Camshaft 1
Loading…
↗
3
66M−11537−00−94
Gear, driven
Loading…
↗
4
97013−06016
Bolt, hexagon deep recess
Loading…
↗
5
90201−13201
Washer 6474283300
Loading…
↗
6
90201−06M94
Washer (6g8)
Loading…
↗
7
66M−11536−10
Gear, drive
Loading…
↗
8
66M−11557−00
8−
Loading…
↗
9
90170−28M37
Nut
Loading…
↗
10
90280−03M01
Key woodruff 146115450000
Loading…
↗
11
66M−46241−00
Belt
Loading…
↗
12
66M−46297−00
Cover, dust
Loading…
↗
13
90480−10M16
Grommet(6j8)
Loading…
↗
14
90480−12072
Grommet(53y)
Loading…
↗
15
66M−13300−10
Oil Pump assembly
Loading…
↗
16
66M−13329−10
Gasket, pump cover
Loading…
↗
17
97095−06035
Bolt(j52)
Loading…
↗
18
92995−06600
Washer, plain (646)
Loading…
↗
