L250AETO (2005)
OIL PUMP
Diagram: OIL PUMP
Parts List
Reference
Description
Price
1
62J1320001
Oil Injection Pump assembly
Loading…
↗
2
6R31347100
Screw
Loading…
↗
3
6L21347500
Gasket, breather bolt
Loading…
↗
4
9321019M82
O-ring(6j8)
Loading…
↗
5
9046407M05
Clamp (6g5)
Loading…
↗
6
9010906M40
Bolt(6h0)
Loading…
↗
7
61A1341600
Pipe, Oil 1
Loading…
↗
8
9046511M10
Clamp
Loading…
↗
9
9044507M77
Hose (l390)
Loading…
↗
10
9044507M72
Hose (l390)
Loading…
↗
11
9044507196
Hose (l200)
Loading…
↗
15
6R31318310
Valve, check
Loading…
↗
16
9044507M87
Hose(62t)
Loading…
↗
17
9044507M07
Hose(62t)
Loading…
↗
19
9046807M02
Clip (6e5)
Loading…
↗
20
61A1153700
Gear, driven
Loading…
↗
21
9020109M01
Washer, plate(61b)
Loading…
↗
22
61A1311700
Collar, distance
Loading…
↗
23
9321018MA9
O-ring(61a)
Loading…
↗
24
61A4123700
Joint, link
Loading…
↗
25
9538005600
Nut, hexagon (663)
Loading…
↗
26
6H14123700
Joint, link
Loading…
↗
27
9149012012
Pin, cotter (6g8)
Loading…
↗
28
9020205088
Washer, plate (666)
Loading…
↗
