Yamaha Outboard Parts - OIL PUMP - Z200NETO (2003) | Flood Marine

Diagram: OIL PUMP

Diagram

Parts List

Reference
Description
Price


1
68L−13200−00
Oil injection pump assembly
Loading…

↗
1
68F−13200−00
Oil injection pump assembly
Loading…

↗
1
68H−13200−00
Oil injection pump assembly
Loading…

↗
2
6R3−13471−00
Screw
Loading…

↗
3
6L2−13475−00
Gasket, breather bolt
Loading…

↗
4
93210−19M82
O-ring(6j8)
Loading…

↗
5
90109−06M40
Bolt(6h0)
Loading…

↗
6
6G5−13416−00
Pipe, oil 1
Loading…

↗
7
90465−11M10
Clamp
Loading…

↗
8
90445−07M00
Hose (l200)
Loading…

↗
9
90445−07M09
Hose (l390)
Loading…

↗
10
90445−07MA5
Hose (l200)
Loading…

↗
11
90445−07M10
Hose (L510)
Loading…

↗
12
90445−07MA4
Hose (l390)
Loading…

↗
13
90445−07M80
Hose (l770)
Loading…

↗
14
90468−07M02
Clip (6e5)
Loading…

↗
15
6R3−13183−00
Valve, check
Loading…

↗
16
90445−07M04
Hose(62t)
Loading…

↗
17
90464−07M20
Clamp(6h0)
Loading…

↗
18
90464−07M05
Clamp (6g5)
Loading…

↗
19
6R3−11537−00
Gear, driven
Loading…

↗
20
6R3−13117−00
Collar, distance
Loading…

↗
21
93210−13M04
93210-13m04
Loading…

↗
22
90202−08M44
Washer, plate(6r3)
Loading…

↗
23
67H−41241−00
Rod, link
Loading…

↗
24
6H1−41237−00
Joint, link
Loading…

↗
25
95380−05600
Nut, hexagon (663)
Loading…

↗
26
6R5−41237−00
Joint, link
Loading…

↗
27
90468−05M03
Clip(6j8)
Loading…

↗
28
90202−05088
Washer, plate (666)
Loading…

↗
29
90445−12M14
Hose (l50)
Loading…

↗
31
90467−08M18
Clip
Loading…

↗
32
68F−13100−00
Solenoid pump assembly
Loading…

↗
33
68F−13418−00
Hose 4
Loading…

↗
34
68F−13184−00
Spring, oil pipe
Loading…

↗
35
68F−13440−00
Filter assembly
Loading…

↗
36
68F−1316F−00
Hose 1
Loading…

↗
37
68F−13133−00
Clip
Loading…

↗
38
68F−1316G−00
Hose 2
Loading…

↗
39
68F−1316A−00
Check Valve assembly
Loading…

↗
40
68F−13416−00
Hose 3
Loading…

↗
41
68F−14485−00
Pipe, joint
Loading…

↗
42
68F−1319K−00
Plate
Loading…

↗
43
97095−06020
Bolt(7u8)
Loading…

↗
44
92995−06100
Washer(6a1)
Loading…

↗
45
92995−06600
Washer, plain (646)
Loading…

↗
46
90110−06M06
Bolt, hexagon socket head
Loading…

↗
