Z250DETO (2005)
OIL PUMP
Diagram: OIL PUMP
Parts List
Reference
Description
Price
1
60V1320011
Oil injection pump assembly
Loading…
↗
2
6R31347100
Screw
Loading…
↗
3
6L21347500
Gasket, breather bolt
Loading…
↗
4
9321019M82
O-ring(6j8)
Loading…
↗
5
9010906M40
Bolt(6h0)
Loading…
↗
6
6G51341600
Pipe, oil 1
Loading…
↗
7
9044617MA8
Hose (L200)
Loading…
↗
8
9046511M10
Clamp
Loading…
↗
9
9044607M35
Hose(62t)
Loading…
↗
10
9044507M96
Hose(62t)
Loading…
↗
11
9044607M48
Hose(62t)
Loading…
↗
12
9044507M44
Hose (l390)
Loading…
↗
13
9044507M46
Hose (l390)
Loading…
↗
14
9044507M10
-
Loading…
↗
15
9044507M04
Hose(62t)
Loading…
↗
16
6R31318310
Valve, check
Loading…
↗
17
9046807M02
Clip (6e5)
Loading…
↗
18
9046407M05
Clamp (6g5)
Loading…
↗
20
9046407M20
Clamp(6h0)
Loading…
↗
21
61A1153700
Gear, driven
Loading…
↗
22
9020109M01
Washer, plate(61b)
Loading…
↗
23
61A1311700
Collar, distance
Loading…
↗
24
9321018MA9
O-ring(61a)
Loading…
↗
25
6R54123700
Joint, link
Loading…
↗
26
65L4124110
-
Loading…
↗
27
9538005600
Nut, hexagon (663)
Loading…
↗
28
6H14123700
Joint, link
Loading…
↗
29
9149012012
Pin, cotter (6g8)
Loading…
↗
30
9020205088
Washer, plate (666)
Loading…
↗
31
60V2431900
Pipe, oil
Loading…
↗
33
9046708M18
Clip
Loading…
↗
34
68F1310000
Solenoid pump assembly
Loading…
↗
35
68F1341800
Hose 4
Loading…
↗
36
68F1318400
Spring, oil pipe
Loading…
↗
37
68F1344000
Filter assembly
Loading…
↗
38
68F1316F00
Hose 1
Loading…
↗
39
68F1313300
Clip
Loading…
↗
40
68F1316G00
Hose 2
Loading…
↗
41
68F1316A00
Check Valve assembly
Loading…
↗
42
68F1341600
Hose 3
Loading…
↗
43
9044808001
Hose, with union
Loading…
↗
44
68F1448500
Pipe, joint
Loading…
↗
45
60V1319K00
Plate
Loading…
↗
46
9709506020
Bolt(7u8)
Loading…
↗
47
9299506100
Washer(6a1)
Loading…
↗
48
9299506600
Washer, plain (646)
Loading…
↗
49
9011006M06
Bolt, hexagon socket head
Loading…
↗
