Yamaha Outboard Parts - OPTIONAL PARTS 5 - F25GET (2018) | Flood Marine

Diagram: OPTIONAL PARTS 5

Diagram

Parts List

Reference
Description
Price


1
9018510027
Nut, self-locking
Loading…

↗
2
63D4832111
Cable
Loading…

↗
3
63D4853800
Clamp, cable 1
Loading…

↗
4
9046810005
Pin, hair 6264123500
Loading…

↗
5
6FM2630110
Throttle cable assembly
Loading…

↗
8
9046409M42
Clamp(6b0)
Loading…

↗
9
6X48258610
Ext., wire harness (l:950mm)
Loading…

↗
10
6X48186000
Switch assembly
Loading…

↗
11
9046513M39
Clamp(6e8)
Loading…

↗
