Yamaha Outboard Parts - POWER UNIT - PSX2SK (2026) | Flood Marine

Diagram: POWER UNIT

Diagram

Parts List

Reference
Description
Price


1
X2S17061K0 C2, '26
-
Loading…

↗
2
X2S8189002
Motor assembly
Loading…

↗
3
X0P8715301
Cover, stator
Loading…

↗
4
9201405016
Bolt, button head(4tr)
Loading…

↗
5
X2S1751000
Housing comp.
Loading…

↗
6
X2S1742100
Axle, drive
Loading…

↗
7
X2S1706200
Torque sensor assembly
Loading…

↗
8
9020617002
Washer, wave
Loading…

↗
9
X2S1630000
Clutch assembly
Loading…

↗
10
9310617001
Oil seal
Loading…

↗
11
9321027003
O-ring
Loading…

↗
12
X2S1662A00
Circlip
Loading…

↗
13
X2S1784000
Driven gear assembly
Loading…

↗
14
X2S1752400
Holder
Loading…

↗
15
9010505029
Bolt, flange
Loading…

↗
16
X2S8617100
Wire, lead 1
Loading…

↗
17
X2S86172A1
Wire, lead 2
Loading…

↗
18
X2S1782200
Holder, sensor
Loading…

↗
19
9015904053
Screw, with washer(5h5)
Loading…

↗
20
9016403009
Screw, tapping
Loading…

↗
21
X2S86212K0
-
Loading…

↗
22
X2S8A8B010
Sheet
Loading…

↗
23
X2S8A8B110
Sheet 1
Loading…

↗
24
X941746330 BLACK
Nut, lock
Loading…

↗
