4BCMH (2003)
REPAIR KIT
Diagram: REPAIR KIT
Parts List
Reference
Description
Price
1
6E3−W0001−A4
Power head gasket kit
Loading…
↗
1
6E0−W0001−A4
Gasket kit
Loading…
↗
2
93210−42159
O-ring (647)
Loading…
↗
3
93102−20M25
Oil seal (6e0)
Loading…
↗
4
6E0−41112−A1
Gasket,inner cover exhaust
Loading…
↗
4
6E3−41112−A1
Gasket,inner cover exhaust
Loading…
↗
5
6E0−41114−A1
Gasket,outer cover exhaust
Loading…
↗
5
6E3−41114−A1
Gasket,outer cover exhaust
Loading…
↗
6
6E0−11193−A1
Gasket,head cover
Loading…
↗
6
6E3−11193−A1
Gasket,head cover
Loading…
↗
7
93101−20M29
Oil seal(6j1)
Loading…
↗
8
93101−10M25
Oil seal(6e0)
Loading…
↗
9
93210−31MJ5
O-ring
Loading…
↗
10
6E0−13621−A2
Gasket, valve seat
Loading…
↗
11
6E0−14198−A0
Gasket
Loading…
↗
12
6E0−14384−00
Gasket, float chamber
Loading…
↗
13
646−14198−01
Gasket
Loading…
↗
14
6E0−45113−A1
Gasket,upper casing
Loading…
↗
15
646−44365−00
Damper, water seal 1
Loading…
↗
16
6E0−W0093−04
Carbureetor repair kit
Loading…
↗
19
97980−04116
Screw, with washer(61b)
Loading…
↗
21
6E7−14385−01
Float
Loading…
↗
22
647−14386−00
Pin, float
Loading…
↗
23
6F5−14392−00
Valve, needle
Loading…
↗
24
6E0−14227−00
Gasket
Loading…
↗
25
647−14323−00
Screw, air adjusting
Loading…
↗
26
6E0−24471−00
Diaphragm
Loading…
↗
27
6E0−24411−00
Diaphragm
Loading…
↗
28
6E0−W0001−C1
L0wer unit gasket kit
Loading…
↗
29
93101−10M14
Oil seal
Loading…
↗
30
90430−08020
Gasket
Loading…
↗
31
6E0−45315−A0
Packing,lower casing
Loading…
↗
32
6E0−44315−A0
Gasket,water pump 1
Loading…
↗
33
93101−13M12
Oil seal
Loading…
↗
34
93210−48214
O-ring
Loading…
↗
35
6E0−W0078−A3
Water pump repair kit
Loading…
↗
36
6E0−44311−00
Housing, water pump
Loading…
↗
38
6E0−44322−02
Insert, cartridge
Loading…
↗
39
6E0−44323−00
Outer plate, cartridge
Loading…
↗
40
6E0−44366−00
Damper, water seal 2
Loading…
↗
41
6E0−44352−00
Impeller
Loading…
↗
42
97095−06045
Bolt, hexagon
Loading…
↗
43
93604−18080
Pin. dowel. (647)
Loading…
↗
44
6E0−W0078−0A
11 −
Loading…
↗
45
6E0−44322−40
Insert, cartridge
Loading…
↗
46
6E0−44323−40
Outer plate, cartridge
Loading…
↗
