20DMHO (2002)
REPAIR KIT 1
Diagram: REPAIR KIT 1
Parts List
Reference
Description
Price
1
6L2−W0001−03
Power head gasket kit
Loading…
↗
2
93102−25142
Oil seal (24.8x38x7-662)
Loading…
↗
3
93101−13M37
Oil seal(6a4)
Loading…
↗
4
93210−56M80
O-ring(6j8)
Loading…
↗
5
6L2−11181−A2
Gasket, cylinder head 1
Loading…
↗
6
6L2−11193−A1
Gasket, head cover 1
Loading…
↗
7
6J8−12414−A0
Gasket, cover
Loading…
↗
8
6L2−41114−A1
Gasket, exhaust outer cover
Loading…
↗
9
6L2−41112−A1
Gasket, exhaust inner cover
Loading…
↗
10
93102−26M27
Oil seal(6j8)
Loading…
↗
11
93210−42159
O-ring (647)
Loading…
↗
12
6L2−13621−00
Gasket, valve seat
Loading…
↗
13
6L2−14384−00
Gasket, float chamber
Loading…
↗
14
6L2−14198−00
Gasket
Loading…
↗
15
93210−32738
O-ring(1wg)
Loading…
↗
16
6L2−45113−A1
Gasket, upper casing
Loading…
↗
17
6L2−41133−A1
Gasket, exhaust manifold 1
Loading…
↗
18
6L2−W0093−00
Carburetor repair kit
Loading…
↗
21
6L2−14385−00
Float
Loading…
↗
22
6E5−14386−01
Pin, float
Loading…
↗
23
6L2−14392−00
Valve, needle
Loading…
↗
24
6L2−14399−00
Gasket
Loading…
↗
25
97980−04112
Screw, pan head (686)
Loading…
↗
26
6L2−14398−00
Gasket
Loading…
↗
