50GETO (2002)
REPAIR KIT 1
Diagram: REPAIR KIT 1
Parts List
Reference
Description
Price
1
62FW000101
Power Head Gasket Kit
Loading…
↗
1
6H3--W0001--02
AUTO CHOKE
Power head gasket kit
Loading…
↗
2
6H311181A1
Gasket, cylinder head 1
Loading…
↗
3
90430--14115
Gasket (663)
Loading…
↗
4
6H3--11193--A1
Gasket, head cover 1
Loading…
↗
5
6H3--12414--A1
Gasket, cover
Loading…
↗
6
6H3--41112--A0
Gasket, exhaust inner cover
Loading…
↗
7
6H3--41114--A0
Gasket, exhaust outer cover
Loading…
↗
8
93102--36M24
Oil seal(52w)
Loading…
↗
9
93210--46M16
O-ring (688)
Loading…
↗
10
93102--30M23
Oil seal (6h3)
Loading…
↗
11
93106--18M01
Oil seal (6h3)
Loading…
↗
12
93210--65M50
O-ring
Loading…
↗
13
6H3--13621--A1
Gasket, valve seat
Loading…
↗
14
93210--39ME4
O-ring(6h2)
Loading…
↗
14
6H4--14198--01
Gasket
Loading…
↗
15
6H4--14984--00
Gasket, float chamber
Loading…
↗
16
93210--32738
O-ring(1wg)
Loading…
↗
17
650--24431--A0
Gasket,fuel pump
Loading…
↗
18
6H3--45113--A0
Gasket, upper casing
Loading…
↗
19
6H3--13622--A1
Gasket, valve seat
Loading…
↗
20
6H2--W0093--10
AUTO CHOKE
Carburetor repair kit
Loading…
↗
20
62FW009300
Carburetor Repair Kit
Loading…
↗
21
6H4--14147--00
O-ring
Loading…
↗
22
93210--04228
O-ring (371)
Loading…
↗
23
6H4--14590--00
Needle valve assembly
Loading…
↗
23
6H31459000
Needle valve assembly
Loading…
↗
24
6H4--14548--00
Pin, float arm
Loading…
↗
25
663--14159--00
Clip
Loading…
↗
26
676--14186--00
Pin, valve
Loading…
↗
27
676--14966--00
Rubber cap
Loading…
↗
29
93210--04230
O-ring (371)
