90AETO (2014)
REPAIR KIT 1
Diagram: REPAIR KIT 1
Parts List
Reference
Description
Price
1
6H1W000102
Power head gasket kit
Loading…
↗
2
9321046044
O-ring
Loading…
↗
3
9321039ME4
O-ring(6h2)
Loading…
↗
4
68813621A1
Gasket, valve seat
Loading…
↗
5
6H41498400
Gasket, float chamber
Loading…
↗
6
68811181A2
Gasket, cylinder head 1
Loading…
↗
7
9043014115
Gasket (663)
Loading…
↗
8
68811193A1
Gasket, head cover 1
Loading…
↗
9
68812414A1
Gasket, cover
Loading…
↗
10
68841112A0
Gasket, exhaust inner cover
Loading…
↗
11
68841114A0
Gasket, exhaust outer cover
Loading…
↗
12
9321046M16
O-ring (688)
Loading…
↗
13
9310236M02
Oil seal(52w)
Loading…
↗
14
9310230M05
Oil seal (688)
Loading…
↗
15
9310420M02
Oil seal (688)
Loading…
↗
16
9321062269
Ring, o(663)
Loading…
↗
17
68845113A0
Gasket, upper casing
Loading…
↗
18
9321032738
O-ring(1wg)
Loading…
↗
19
65024431A0
Gasket,fuel pump
Loading…
↗
20
6H1W009310
Carburetor repair kit
Loading…
↗
21
6H41414700
O-ring
Loading…
↗
22
9321004228
O-ring (371)
Loading…
↗
23
6921459001
Needle valve assembly
Loading…
↗
24
6H41454800
Pin, float arm
Loading…
↗
25
6631415900
Clip
Loading…
↗
26
6761418600
Pin, valve
Loading…
↗
27
6761496600
Rubber cap
Loading…
↗
29
9321004230
O-ring (371)
Loading…
↗
