F100FET (2019)
REPAIR KIT 1
Diagram: REPAIR KIT 1
Parts List
Reference
Description
Price
1
6FPW000100
Power head gasket kit
Loading…
↗
2
9043014115
Gasket (663)
Loading…
↗
3
9310248017
Oil seal
Loading…
↗
4
9321013M63
O-ring (6g8)
Loading…
↗
5
9043006014
Gasket 256113960000
Loading…
↗
6
6FP1118100
Gasket, cylinder head 1
Loading…
↗
7
6FP1119300
Gasket, head cover 1
Loading…
↗
8
9321019MJ1
O-ring
Loading…
↗
9
6EK1135100
Gasket, cylinder
Loading…
↗
11
90201186F1
Washer, plate (22f)
Loading…
↗
12
6FP1535300
Gasket, drain
Loading…
↗
13
9310285008
Oil seal
Loading…
↗
14
6FP1364500
Gasket, manifold 1
Loading…
↗
15
6FP1364600
Gasket, manifold 2
Loading…
↗
16
69J1135500
Seal, cylinder 1
Loading…
↗
18
6FP1347500
Gasket
Loading…
↗
19
9321024M79
O-ring
Loading…
↗
20
9321030682
O-ring (371)
Loading…
↗
