Yamaha Outboard Parts - REPAIR KIT 1 - FL200CET (2022) | Flood Marine

Diagram: REPAIR KIT 1

Diagram

Parts List

Reference
Description
Price


1
6P2W000104
Power head gasket kit
Loading…

↗
2
6P21118100
Gasket, cylinder head 1
Loading…

↗
3
6P21118200
Gasket, cylinder head 2
Loading…

↗
4
6P21119300
Gasket, head cover 1
Loading…

↗
5
6P21119400
Gasket, head cover 2
Loading…

↗
6
6P24111200
Gasket, exhaust inner cover
Loading…

↗
7
6P24112200
Gasket, exhaust inner cover
Loading…

↗
8
6P24111400
Gasket, exhaust outer cover
Loading…

↗
9
90201186F1
Washer, plate (22f)
Loading…

↗
10
69J1545101
Gasket, crankcase cover 1
Loading…

↗
11
6P21131B00
Gasket, cover
Loading…

↗
12
9043005002
Gasket
Loading…

↗
13
69J1135112
Gasket, cylinder
Loading…

↗
14
9321025552
O-ring (22f)
Loading…

↗
15
9321019MJ1
O-ring
Loading…

↗
16
9321025647
O-ring (7or)
Loading…

↗
17
69J1466400
Grommet, water shut
Loading…

↗
18
9310263004
Oil seal
Loading…

↗
19
9310238008
Oil seal
Loading…

↗
20
69J1135500
Seal, cylinder 1
Loading…

↗
21
6P21347700
Gasket
Loading…

↗
22
9321019MJ3
O-ring
Loading…

↗
23
9321024M79
O-ring
Loading…

↗
24
6CB1242F00
Gasket, filter
Loading…

↗
