Yamaha Outboard Parts - REPAIR KIT 1 - FL350AET (2014) | Flood Marine

Diagram: REPAIR KIT 1

Diagram

Parts List

Reference
Description
Price


1
6AWW000101
Power head gasket kit
Loading…

↗
2
6AW1118100
Gasket, cylinder head 1
Loading…

↗
3
6AW1118200
Gasket, cylinder head 2
Loading…

↗
4
6AW1119310
Gasket, head cover 1
Loading…

↗
5
6AW1119410
Gasket, head cover 2
Loading…

↗
6
6AW1545100
Gasket, crankcase cover 1
Loading…

↗
7
6AW1536400
Gasket, oil plug
Loading…

↗
8
6AW1546100
Gasket, crankcase cover 2
Loading…

↗
9
6AW1242700
Gasket, housing cover 1
Loading…

↗
10
9043005002
Gasket
Loading…

↗
11
93210207A0
O-ring
Loading…

↗
12
6AW1135100
Gasket, cylinder
Loading…

↗
13
9321026658
O-ring(36y)
Loading…

↗
14
6AW1466400
Grommet, water shut
Loading…

↗
15
6AW1138100
Gasket 1
Loading…

↗
16
9310285004
Oil seal
Loading…

↗
17
9310238008
Oil seal
Loading…

↗
18
69J1135500
Seal, cylinder 1
Loading…

↗
20
6AW1347700
Gasket
Loading…

↗
21
9321024M79
O-ring
Loading…

↗
22
6CB1242F00
Gasket, filter
Loading…

↗
