LZ300AETO (2005)
REPAIR KIT 1
Diagram: REPAIR KIT 1
Parts List
Reference
Description
Price
1
6D0W000100
-
Loading…
↗
2
60V1119300
Gasket, head cover 1
Loading…
↗
3
6D01118100
Gasket, cylinder head 1
Loading…
↗
4
9043014115
Gasket (663)
Loading…
↗
5
60V1138100
Gasket 1
Loading…
↗
6
60V12414A0
Gasket, cover
Loading…
↗
7
60V4111200
Gasket, exhaust inner cover
Loading…
↗
8
60V11382A0
Gasket 2
Loading…
↗
9
9310422M07
Oil seal(61a)
Loading…
↗
10
9310340011
Oil seal
Loading…
↗
11
9321085M32
O-ring (173)
Loading…
↗
12
60V1364600
Gasket, manifold 2
Loading…
↗
13
60V1364500
Gasket, manifold 1
Loading…
↗
14
60V1447600
Seal
Loading…
↗
15
9321018MA9
O-ring(61a)
Loading…
↗
16
60V13621A0
Gasket, Valve Seat
Loading…
↗
17
60V1147900
O-ring
Loading…
↗
18
60V4511301
Gasket, upper casing
Loading…
↗
19
6D01545100
Gasket, Crankcase Cover 1
Loading…
↗
20
6D01546100
Gasket, crankcase cover 2
Loading…
↗
21
6D01546200
Gasket, crankcase cover 3
Loading…
↗
