Z175GETO (2003)
REPAIR KIT 1
Diagram: REPAIR KIT 1
Parts List
Reference
Description
Price
1
68F−W0001−00
Power head gasket kit
Loading…
↗
2
65L−13645−00
Gasket, manifold 1
Loading…
↗
3
65L−13646−00
Gasket, manifold 2
Loading…
↗
4
61A−13621−A0
Gasket, valve seat
Loading…
↗
5
65L−14483−00
Gasket
Loading…
↗
6
90430−14115
Gasket (663)
Loading…
↗
7
68F−11381−00
Gasket 1
Loading…
↗
8
68F−41114−00
Gasket, exhaust outer cover
Loading…
↗
9
6G5−11382−A1
Gasket 2
Loading…
↗
10
68F−11181−00
Gasket, cylinder head 1
Loading…
↗
11
68F−11193−01
Gasket, head cover 1
Loading…
↗
12
688−12414−A1
Gasket, cover
Loading…
↗
13
93102−40M14
Oil seal(61a)
Loading…
↗
14
93211−04001
O-ring
Loading…
↗
15
93102−35M61
Oil seal
Loading…
↗
16
93101−22M15
Oil seal (6e5)
Loading…
↗
17
93210−74M35
O-ring (6e5)
Loading…
↗
18
68F−45113−00
Gasket, upper casing
Loading…
↗
