75CETO (2003)
REPAIR KIT 2
Diagram: REPAIR KIT 2
Parts List
Reference
Description
Price
1
688W000121
Lower unit gasket kit
Loading…
↗
2
688--45114--A1
Gasket, upper casing
Loading…
↗
3
688--41134--A0
Gasket, exhaust manifold
Loading…
↗
4
688--41133--00
Gasket, exhaust manifold 1
Loading…
↗
5
688--45123--00
Gasket, muffler
Loading…
↗
6
90430--08020
Gasket
Loading…
↗
7
93210--49046
O-ring (620)
Loading…
↗
8
93106--09014
Oil seal
Loading…
↗
9
688--44315--A0
Gasket,water pump 1
Loading…
↗
10
688--44324--A0
Gasket,cartridge 0uter plate
Loading…
↗
11
688--44316--A0
Gasket,water pump 2
Loading…
↗
12
93210--46044
O-ring
Loading…
↗
13
93210--85M97
O-ring(6h1)
Loading…
↗
14
93101--25M03
Oil seal
Loading…
↗
15
90430--12072
Gasket
Loading…
↗
16
663--44366--00
Damper, water seal 2
Loading…
↗
17
692--W0078--02
Water pump repair kit
Loading…
↗
18
688--44322--00
Insert, cartridge
Loading…
↗
19
688--44352--03
Impeller
Loading…
↗
21
688--44323--00
Outer plate, cartridge
Loading…
↗
25
90119--08M13
Bolt, with washer(6h0)
Loading…
↗
26
90119--08M16
Bolt, with washer(6h0)
Loading…
↗
27
90280--04M04
Key, woodruff (688)
Loading…
↗
28
688--W0078--1A
Chrome pump kit
Loading…
↗
29
688--44321--41
Inner plate, cartridge
Loading…
↗
30
688--44322--41
Insert, cartridge
Loading…
↗
31
688--44323--40
Outer plate, cartridge
Loading…
↗
