F80AET (2003)
REPAIR KIT 3
Diagram: REPAIR KIT 3
Parts List
Reference
Description
Price
1
67F−W0001−21
Lower unit gasket kit
Loading…
↗
2
90430−08020
Gasket
Loading…
↗
3
688−44315−A0
Gasket,water pump 1
Loading…
↗
4
688−44324−A0
Gasket,cartridge 0uter plate
Loading…
↗
5
93101−25M03
Oil seal
Loading…
↗
6
93210−46044
O-ring
Loading…
↗
7
688−44316−A0
Gasket,water pump 2
Loading…
↗
8
93106−09014
Oil seal
Loading…
↗
9
93210−49046
O-ring (620)
Loading…
↗
10
93210−07003
O-ring (11m)
Loading…
↗
11
93210−86M39
O-ring (6e5)
Loading…
↗
12
90430−14M09
Gasket
Loading…
↗
13
68V−15312−00
Gasket, oil pan
Loading…
↗
14
67F−13415−00
Seal, oil strainer
Loading…
↗
15
93210−19MJ1
O-ring
Loading…
↗
16
67F−41133−A1
Gasket, exhaust manifold 1
Loading…
↗
17
67F−41134−A0
Gasket, exhaust manifold
Loading…
↗
18
67F−41138−00
Seal, ext. 1
Loading…
↗
19
67F−45127−00
Seal
Loading…
↗
20
67F−45123−00
Gasket, muffler
Loading…
↗
21
67F−45113−00
Gasket, upper casing
Loading…
↗
22
67F−W0078−00
Water pump repair kit
Loading…
↗
23
67F−44322−00
Insert, cartridge
Loading…
↗
24
67F−44352−00
Impeller
Loading…
↗
26
67F−44323−00
Outer plate, cartridge
Loading…
↗
30
90119−08M87
Bolt, with washer
Loading…
↗
31
90119−08M13
Bolt, with washer(6h0)
Loading…
↗
32
90280−04M04
Key, woodruff (688)
Loading…
↗
