F50AET (2002)
REPAIR KIT 5
Diagram: REPAIR KIT 5
Parts List
Reference
Description
Price
1
64JW00012B
FT50C
Lower unit gasket kit
Loading…
↗
2
62Y1347500
Gasket
Loading…
↗
3
69W1531200
Gasket, oil pan
Loading…
↗
4
9043014M09
Gasket
Loading…
↗
5
9310318011
Oil seal
Loading…
↗
6
64J4113310
Gasket, exhaust manifold 1
Loading…
↗
7
62Y4113401
Gasket, exhaust manifold
Loading…
↗
8
62Y4512700
Seal
Loading…
↗
9
6634512300
Gasket, muffler
Loading…
↗
10
9043008020
Gasket
Loading…
↗
11
9321049046
O-ring (620)
Loading…
↗
12
9310609014
Oil seal
Loading…
↗
13
6H344315A0
Gasket,water pump 1
Loading…
↗
14
9310123070
Oil seal (663)
Loading…
↗
15
9321046044
O-ring
Loading…
↗
16
68844316A0
Gasket,water pump 2
Loading…
↗
17
6H344324A0
Gasket,cartridge 0ut,plate
Loading…
↗
18
9321086M39
O-ring (6e5)
Loading…
↗
19
9310125M03
Oil seal
Loading…
↗
20
6634436600
Damper, water seal 2
Loading…
↗
21
9321007003
O-ring (11m)
Loading…
↗
22
6H3W007802
FT50C
Water pump repair kit
Loading…
↗
23
6634432200
Insert, cartridge
Loading…
↗
24
6H34435200
Impellar
Loading…
↗
26
6H34432300
Outer plate, cartridge
Loading…
↗
30
9011908M14
Bolt, with washer
Loading…
↗
31
9011908M33
Bolt, with washer(6b0)
Loading…
↗
32
9028003M03
Key, woodruff (697)
Loading…
↗
33
6H3W00780A
FT50C
Chrome pump kit
Loading…
↗
34
6704432201
Insert, cartridge
Loading…
↗
35
6704432100
Inner plate, cartridge
Loading…
↗
36
6H34432340
Outer plate, cartridge
Loading…
↗
