30AMH (1985)
Repair Kit
Diagram: Repair Kit
Parts List
Reference
Description
Price
1
689W00930000
Carburetor repair kit
Loading…
↗
2
648141980000
Gasket
Loading…
↗
3
648143840100
Gasket,float chamber
Loading…
↗
4
648143850000
Float
Loading…
↗
5
985010401200
Screw, pan head
Loading…
↗
6
929900410000
Ybs67-4 washer, spring
Loading…
↗
7
648143901400
Needle valve assembly
Loading…
↗
8
647143230000
Screw, air adjusting
Loading…
↗
9
903860500200
Bush 626412910000
Loading…
↗
10
646143970000
Ring O (664)
Loading…
↗
11
689W00010200
Power Head Gasket Kit
Loading…
↗
12
9321162M2400
O-Ring (689)
Loading…
↗
13
64813621A100
Gasket, valve seat
Loading…
↗
14
648136450000
Gasket, manifold 1
Loading…
↗
15
64814198A000
Gasket
Loading…
↗
17
689111810100
Gasket, cylinder head 1
Loading…
↗
18
65512414A100
Gasket, cover
Loading…
↗
19
689153690000
Gasket Oil Seal Housing
Loading…
↗
20
9310225M1100
Oil Seal (689)
Loading…
↗
21
68941114A000
Gasket, exhaust outer cover
Loading…
↗
22
689411120000
Gasket, exhaust inner cover
Loading…
↗
23
932101627500
O-ring
Loading…
↗
24
9321057M0900
O-ring (683)
Loading…
↗
25
9310225M0400
Oil seal(6h4)
Loading…
↗
26
9310116M3600
Oil seal(6a8)
Loading…
↗
27
689451130100
Gasket, upper casing
Loading…
↗
28
655245640000
Packing, filter
Loading…
↗
29
9321037M2500
O-ring (655)
Loading…
↗
30
65024431A000
Gasket,fuel pump
Loading…
↗
31
689W00012200
Gasket kit, lower unit
Loading…
↗
32
66441134A000
Gasket, exhaust manifold
Loading…
↗
33
689443660000
Damper, water seal 2
Loading…
↗
34
904300802000
Gasket
Loading…
↗
35
689443240100
Gasket, cartridge
Loading…
↗
36
9321040M1000
O-ring (682)
Loading…
↗
37
931012206700
Oil seal (22x36x6-663)
Loading…
↗
38
68944315A000
Gasket, water pump
Loading…
↗
39
9321060M1700
O-ring(6j8)
Loading…
↗
40
9310120M0700
Oil seal
Loading…
↗
41
68944316A000
Gasket, water pump
Loading…
↗
42
689W00780500
Water pump repair kit
Loading…
↗
43
626443650100
Damper, water seal 1
Loading…
↗
44
689443110300
Housing, water pump
Loading…
↗
45
970800603000
Bolt(jf7)
Loading…
↗
46
689W44320200
Insert cartridge comp.
Loading…
↗
47
689443230300
Outer plate, cartridge
Loading…
↗
49
689443520200
Impeller
Loading…
↗
50
689443160000
Gasket, water pump
Loading…
↗
51
664443380000
Key, woodruff
Loading…
↗
