40HM (1985)
Repair Kit
Diagram: Repair Kit
Parts List
Reference
Description
Price
1
6H4W00010000
Gasket kit, power unit
Loading…
↗
2
6H4111810000
Gasket, cylinder head 1
Loading…
↗
3
6H4111930000
Gasket, head cover 1
Loading…
↗
4
904301411500
Gasket (663)
Loading…
↗
5
6H4124140000
Gasket, cover
Loading…
↗
6
6H4411140000
Gasket, exhaust outer cover
Loading…
↗
7
6H415369A100
Gasket, oil seal housing
Loading…
↗
8
9310416M0100
Oil seal(6a8)
Loading…
↗
9
9310125M3500
Oil seal(6a4)
Loading…
↗
10
9321058M2100
O-ring (683)
Loading…
↗
11
6H4136210000
Gasket, valve seat
Loading…
↗
12
6H4141980900
Gasket, plate
Loading…
↗
13
6H3144570000
Seal
Loading…
↗
14
6G1149840000
Gasket, float chamber
Loading…
↗
15
655245640000
Packing, filter
Loading…
↗
16
9321037M2500
O-ring (655)
Loading…
↗
17
65024431A000
Gasket,fuel pump
Loading…
↗
18
6H4451130000
Gasket, upper casing
Loading…
↗
19
6H4W00930100
Carburetor repair set
Loading…
↗
21
676149660000
Rubber cap
Loading…
↗
22
6H3145900000
Needle valve assembly
Loading…
↗
23
633141590000
Clip
Loading…
↗
24
676141860000
Pin, valve
Loading…
↗
25
6G1149850000
Float comp.
Loading…
↗
26
688145480000
Pin, arm
Loading…
↗
28
979800411400
Screw, pan head(ga5)
Loading…
↗
29
932100423000
O-ring (371)
Loading…
↗
30
663141260000
Packing
Loading…
↗
31
688141260000
Packing
Loading…
↗
32
692149230000
Screw, adjusting
Loading…
↗
33
9321015M5200
O-ring (6e9)
Loading…
↗
34
6H4W00012100
Lower unit gasket kit
Loading…
↗
35
6H4451140000
Gasket, upper casing
Loading…
↗
36
6H441134A000
Gasket, exhaust manifold
Loading…
↗
37
6H4411330000
Gasket, exhaust manifold 1
Loading…
↗
38
663451230000
Gasket, muffler
Loading…
↗
39
904300802000
Gasket
Loading…
↗
40
932104904600
O-ring (620)
Loading…
↗
41
66344315A000
Gasket,water pump 1
Loading…
↗
42
663443240000
Gasket,cartridge outer plate
Loading…
↗
43
663443160000
Gasket,water pump 2
Loading…
↗
44
932104104200
O-ring (132)
Loading…
↗
45
931012307000
Oil seal (663)
Loading…
↗
46
932106626200
O-ring(6h4)
Loading…
↗
47
9310122M0000
Oil seal (22x36x6-663)
Loading…
↗
48
6H4W0078A000
Water pump rerair kit
Loading…
↗
49
663443220000
Insert, cartridge
Loading…
↗
50
6H4443520000
Impeller
Loading…
↗
51
663443150000
Gasket,water pump 1
Loading…
↗
52
663443230000
Outer plate, cartridge
Loading…
↗
55
970950805500
Bolt, hexagon
Loading…
↗
56
973950804500
Bolt, hexagon
Loading…
↗
57
663443660000
Damper, water seal 2
Loading…
↗
58
902800302400
Key, woodruff(662)
Loading…
↗
