60FETO (1985)
Repair Kit
Diagram: Repair Kit
Parts List
Reference
Description
Price
1
6H3W00010000
Gasket kit, power unit
Loading…
↗
2
6H3111810000
Gasket, cylinder head 1
Loading…
↗
3
904301411500
Gasket (663)
Loading…
↗
4
6H3111930000
Gasket, head cover 1
Loading…
↗
5
6H3124140000
Gasket, cover
Loading…
↗
6
6H341112A000
Gasket, exhaust inner cover
Loading…
↗
7
6H3411140000
Gasket, exhaust outer cover
Loading…
↗
8
9310236M2400
Oil seal(52w)
Loading…
↗
9
9321046M1600
O-ring (688)
Loading…
↗
10
9310230M2300
Oil seal (6h3)
Loading…
↗
11
9310618M0100
Oil seal (6h3)
Loading…
↗
12
9321065M5000
O-ring
Loading…
↗
13
6H3136210000
Gasket, valve seat
Loading…
↗
14
6H314198A100
Gasket
Loading…
↗
15
6G1149840000
Gasket, float chamber
Loading…
↗
16
655245640000
Packing, filter
Loading…
↗
17
9321037M2500
O-ring (655)
Loading…
↗
18
65024431A000
Gasket,fuel pump
Loading…
↗
19
6H3451130000
Gasket, upper casing
Loading…
↗
20
6H3W00930100
Carburetor repair kit
Loading…
↗
22
676149660000
Rubber cap
Loading…
↗
23
6H2145910000
Needle valve assembly
Loading…
↗
24
633141590000
Clip
Loading…
↗
25
676141860000
Pin, valve
Loading…
↗
26
6G1149850000
Float comp.
Loading…
↗
27
688145480000
Pin, arm
Loading…
↗
29
979800411400
Screw, pan head(ga5)
Loading…
↗
30
932100423000
O-ring (371)
Loading…
↗
31
663141260000
Packing
Loading…
↗
32
688141260000
Packing
Loading…
↗
33
692149230000
Screw, adjusting
Loading…
↗
34
9321015M5200
O-ring (6e9)
Loading…
↗
35
6H3W0001C100
Gasket kit, lower unit
Loading…
↗
36
6H3451140000
Gasket, upper casing
Loading…
↗
38
6H3451230000
Gasket, muffler
Loading…
↗
39
904300800300
Gasket
Loading…
↗
40
932104904600
O-ring (620)
Loading…
↗
41
931060901400
Oil seal
Loading…
↗
42
6H3443150000
Gasket,water pump 1
Loading…
↗
43
6H344324A000
Gasket,cartridge 0ut,plate
Loading…
↗
44
688443160100
Gasket,water pump 2
Loading…
↗
45
932104604400
O-ring
Loading…
↗
46
931012307000
Oil seal (663)
Loading…
↗
47
9310125M0300
Oil seal
Loading…
↗
48
9321085M1500
O-ring(6h1)
Loading…
↗
49
663443660000
Damper, water seal 2
Loading…
↗
50
6H3W00780000
Water pump rerair kit
Loading…
↗
51
663443220000
Insert, cartridge
Loading…
↗
52
6H3443520000
Impellar
Loading…
↗
54
6H3443230000
Outer plate, cartridge
Loading…
↗
58
970950804500
Bolt, hexagon
Loading…
↗
59
973950805500
Bolt, hexagon
Loading…
↗
60
9028003M0300
Key, woodruff (697)
Loading…
↗
