200GETO (2002)
STARTING MOTOR
Diagram: STARTING MOTOR
Parts List
Reference
Description
Price
1
6N7--81800--10
Starting motor assembly
Loading…
↗
2
6N7--81850--10
Armature assembly
Loading…
↗
3
61A--81809--00
Washer kit
Loading…
↗
4
61A--81824--00
Washer 2
Loading…
↗
5
6N7--81810--00
Stator assembly
Loading…
↗
6
6K7--8182G--10
Bush, terminal
Loading…
↗
7
6N7--81840--00
Brush holder assembly
Loading…
↗
8
6N7--81801--00
Brush set
Loading…
↗
9
6N7--81813--00
Spring, brush
Loading…
↗
10
6N7--81820--10
Rear bracket assembly
Loading…
↗
11
6N7--81807--00
Gear assembly, starting motor
Loading…
↗
12
6N7--81857--00
Pinion stopper set
Loading…
↗
13
6N7--81830--00
Front bracket assembly
Loading…
↗
14
6K7--81826--10
Bolt
Loading…
↗
15
6E5--8182E--10
Washer, spring
Loading…
↗
16
6E5--8182F--10
Washer,plain
Loading…
↗
17
6E5--8182A--10
Nut
Loading…
↗
18
6E5--8182K--10
Nut
Loading…
↗
19
6K7--81822--00--94
Bracket, starting motor
Loading…
↗
20
90119--08M76
Bolt, with washer(6e5)
Loading…
↗
21
90119--08M77
Bolt, with washer(6e5)
Loading…
↗
22
90119--08M57
Bolt, with washer
Loading…
↗
23
92990--08600
Washer, plain (663)
Loading…
↗
24
97095--08016
Bolt, hexagon deep recess
Loading…
↗
25
92995--08600
Washer, plain (663)
Loading…
↗
26
90465--06M86
Clamp
Loading…
↗
27
97095--06012
Bolt(gh1)
Loading…
↗
28
92995--06600
Washer, plain (646)
Loading…
↗
