Yamaha Outboard Parts - STEERING - 25MHB3 (2003) | Flood Marine

Diagram: STEERING

Diagram

Parts List

Reference
Description
Price


2
6G1−42111−11−4D
Handle, steering
Loading…

↗
3
6E0−44191−11
Indicator, shift
Loading…

↗
4
90206−36M21
Washer, wave(63v)
Loading…

↗
5
90202−36M55
Washer, plate(63v)
Loading…

↗
6
90386−33M96
Bush(63v)
Loading…

↗
7
90386−34M97
Bush(63v)
Loading…

↗
8
6G1−42131−01
Cover, handle steering
Loading…

↗
9
97095−06020
Bolt(7u8)
Loading…

↗
10
6G1−42125−01
Bolt, friction adjusting
Loading…

↗
11
6G1−42126−00
Piece, friction
Loading…

↗
12
91490−16010
Pin, cotter
Loading…

↗
13
664−42119−00
Grip, steering handle
Loading…

↗
14
6F6−42177−A0
Rubber, handle
Loading…

↗
15
6J8−42137−00
Indicator, throttle
Loading…

↗
16
90269−02M09
Rivet(6l5)
Loading…

↗
17
90501−23215
Spring (655)
Loading…

↗
18
92903−10600
Washer, plate
Loading…

↗
19
90149−05M13
Screw, countersunk
Loading…

↗
20
90386−08032
Bushing (650)
Loading…

↗
21
6G1−42138−01
Lever, throttle
Loading…

↗
22
6E0−42159−02
Stay
Loading…

↗
23
97885−05012
Screw,pan head (646)
Loading…

↗
24
6J8−26301−00
Throttle cable assembly
Loading…

↗
25
6J8−44111−01−4D
Handle, gear shift
Loading…

↗
26
6J8−44125−00
Lever, shift rod
Loading…

↗
27
682−44132−00
Bushing
Loading…

↗
28
90254−03M04
Pin, spring (6h3)
Loading…

↗
29
90386−06M12
Bushing (688)
Loading…

↗
30
6J8−44124−00
Link, shift rod
Loading…

↗
31
92990−06200
Ybs66-6 washer, plain
Loading…

↗
32
91490−20012
Pin, cotter (648)
Loading…

↗
33
6E0−83627−41
Label, caution 7
Loading…

↗
34
6E0−83627−51 FOR CANADA
Label, Caution 7
Loading…

↗
