40VMHO (2004)
STEERING
Diagram: STEERING
Parts List
Reference
Description
Price
1
63DW0084014D
Handle Steering assembly
Loading…
↗
2
63D42111014D
Handle, Steering
Loading…
↗
3
6K54213700
Indicator, throttle
Loading…
↗
4
9026902M09
Rivet(6l5)
Loading…
↗
5
63D4410011
Shift Link assembly
Loading…
↗
6
63D4410400
Plate Comp.
Loading…
↗
7
63D4826100
Arm, Throttle
Loading…
↗
8
63D4211500
Shaft, Steering Handle
Loading…
↗
9
650421520094
Gear
Loading…
↗
10
9169030025
Pin, spring
Loading…
↗
11
63D4215900
Stay
Loading…
↗
12
9858006016
Screw pan head
Loading…
↗
13
9343008006
Circlip(2r6)
Loading…
↗
14
63D4411301
Cam Plate, Handle
Loading…
↗
15
63D4823600
Roller, detent
Loading…
↗
16
63D4811900
Cover
Loading…
↗
17
63D4215300
Shaft, Throttle Control
Loading…
↗
18
63D4413200
Bushing
Loading…
↗
19
63D4811800
Clip, Shift Lever
Loading…
↗
20
63D4823700
Adaptor
Loading…
↗
21
9878505014
Screw 3
Loading…
↗
22
63D4823800
Spring, detent
Loading…
↗
23
63D4218100
Washer
Loading…
↗
24
9709506016
Bolt, hexagon deep recess
Loading…
↗
25
9299506600
Washer, plain (646)
Loading…
↗
26
63D4213100
Cover, handle steering
Loading…
↗
27
9048014M14
Grommet (6e0)
Loading…
↗
28
9788506016
Screw, pan head(6b0)
Loading…
↗
30
9788506040
Screw pan head
Loading…
↗
32
63D4272500
Grommet
Loading…
↗
33
63D4832101
Cable
Loading…
↗
34
63D2630101
Throttle cable assembly
Loading…
↗
35
9010112M09
Bolt
Loading…
↗
36
9299012200
Ybs66-12 washer,plain
Loading…
↗
37
63D4853100
Bracket, Remote Control 1
Loading…
↗
38
63D4853800
Clamp, cable 1
Loading…
↗
39
9046409M42
Clamp(6b0)
Loading…
↗
42
9038612M93
Bush(6b0)
Loading…
↗
43
9038629M95
Bush
Loading…
↗
44
9299012600
Washer, plate(663)
Loading…
↗
45
9020612M22
Washer, wave(6b0)
Loading…
↗
46
9018512M12
Nut, self-locking(6e5)
Loading…
↗
47
9038712M02
Collar(6b0)
Loading…
↗
48
63D4212600
Friction, steering handle grip
Loading…
↗
49
63D4815400
-
Loading…
↗
50
9538006600
Nut(661)
Loading…
↗
51
9149020010
Pin, cotter
Loading…
↗
52
6G84419100
Indicator, shift
Loading…
↗
53
9020224M53
Washer, Plate
Loading…
↗
54
9709508040
Bolt, hexagon
Loading…
↗
55
9299508600
Washer, plain (663)
Loading…
↗
56
63D4415901
Handle, Gear Shift
Loading…
↗
57
9015906M18
Screw, with washer(6b0)
Loading…
↗
58
63D4417300
Lever, Shift Control
Loading…
↗
59
6644211900
Grip, steering handle
Loading…
↗
60
6G14217700
Rubber, handle
Loading…
↗
61
9014905M13
Screw, countersunk
Loading…
↗
62
9290310600
Washer, plate
Loading…
↗
63
9050123215
Spring (655)
Loading…
↗
64
9038608032
Bushing (650)
Loading…
↗
65
9343004M03
Circlip (eu0)
Loading…
↗
66
63D42121204D
Bracket
Loading…
↗
67
6E08362741
Label, caution 7
Loading…
↗
68
6E08362751
-
Loading…
↗
