Rigging - Remote Control (2011)
SWITCH & PANEL 17
Diagram: SWITCH & PANEL 17
Parts List
Reference
Description
Price
1
6X682570J0
STATION SUB
Panel switch assembly
Loading…
↗
2
6X68259E20
Switch assembly
Loading…
↗
3
6X68257180
Panel, switch
Loading…
↗
4
70383383A0
Buzzer
Loading…
↗
5
6X68271640
Cord switch
Loading…
↗
6
6X68198000
Diode assembly
Loading…
↗
7
6X682570K0
STATION SUB
Panel switch assembly
Loading…
↗
9
6X68257190
Panel, switch
Loading…
↗
13
6X682570V0
STATION MAIN & SUB
Panel switch assembly
Loading…
↗
14
6X68257530
Engine stop switch assembly
Loading…
↗
15
6X68257150
Panel, switch
Loading…
↗
16
6X68255600
Lanyard, stop switch
Loading…
↗
17
6X682570L0
STATION MAIN & SUB
Panel switch assembly
Loading…
↗
18
6X68257170
Panel, switch
Loading…
↗
