Digital Network Control (2010)
SWITCH & PANEL 4 (TWIN)
Diagram: SWITCH & PANEL 4 (TWIN)
Parts List
Reference
Description
Price
1
6Y88257002
& 2 STATION MAIN
Panel switch assembly
Loading…
↗
2
6Y88257101
Plate, panel switch
Loading…
↗
3
6Y88251002
Main switch assembly
Loading…
↗
4
6768257700
Cap, key
Loading…
↗
5
6K18257500
Engine stop switch assembly
Loading…
↗
6
6828255600
Lanyard, stop switch
Loading…
↗
7
6R58338300
Buzzer
Loading…
↗
8
68V8195000
Relay assembly
Loading…
↗
9
6Y88250700
Lead, ignition switch relay
Loading…
↗
10
64D8258100
Stay, cord clamp
Loading…
↗
11
9730305012
Bolt, hexagon
Loading…
↗
12
9290305100
Ybs67-5 washer, spring
Loading…
↗
13
9530305700
Nut (656)
Loading…
↗
14
6X68258AL0
Extension, wire harness
Loading…
↗
