Yamaha Outboard Parts - UPPER CASING - FT60BET (2003) | Flood Marine

Diagram: UPPER CASING

Diagram

Parts List

Reference
Description
Price


2
62Y−11325−00
Anode
Loading…

↗
3
66M−11328−00
Grommet, anode
Loading…

↗
5
66M−12535−00
Plate
Loading…

↗
6
97095−05012
Bolt, hexagon
Loading…

↗
7
92995−05600
Washer, plain (646)
Loading…

↗
8
97013−06020
Bolt(62y)
Loading…

↗
9
92903−06600
Washer, plain (646)
Loading…

↗
10
93103−18011
Oil seal
Loading…

↗
11
69W−41131−00
Manifold, Ext. 1
Loading…

↗
12
64J−46132−10
Gasket 1
Loading…

↗
13
64J−41133−10
Gasket, exhaust manifold 1
Loading…

↗
14
64J−41116−00
Protector
Loading…

↗
15
97075−06050
Bolt(jf7)
Loading…

↗
16
92995−06600
Washer, plain (646)
Loading…

↗
17
90201−06015
Washer, plate
Loading…

↗
20
97075−06025
Bolt
Loading…

↗
22
62Y−41134−01
Gasket, exhaust manifold
Loading…

↗
23
62Y−45127−00
Seal
Loading…

↗
24
67C−45123−00
Gasket, muffler
Loading…

↗
26
90119−08M79
Bolt, hexagon (fj1)
Loading…

↗
27
90119−08M82
Bolt, with washer(697)
Loading…

↗
28
67C−45151−00
Cover, upper casing
Loading…

↗
29
97880−05016
Screw, pan head(6b0)
Loading…

↗
30
92990−05600
Washer, plain (646)
Loading…

↗
31
6H3−45155−00
Cap
Loading…

↗
32
69W−45318−00
Bushing, drive shaft
Loading…

↗
33
93420−36M01
Circlip (6a0)
Loading…

↗
34
90340−14M06
Plug, straight screw(62y)
Loading…

↗
35
90430−14M09
Gasket
Loading…

↗
