XF425NSA (2018)
UPPER CASING 3
Diagram: UPPER CASING 3
Parts List
Reference
Description
Price
1
6GR4536800
Joint, hose 1
Loading…
↗
2
9046511M10
Clamp
Loading…
↗
3
6GR4383K00
Hose, oil 1
Loading…
↗
4
6AW4278500
Pipe
Loading…
↗
6
6GR4536900
Joint, hose 2
Loading…
↗
8
6GR2318F00
Hose, air
Loading…
↗
9
6E52437900
Pipe, joint 4
Loading…
↗
11
9759508525
Bolt, hexagon deep recess
Loading…
↗
12
6GR1249100
Clamp 1
Loading…
↗
13
9709506012
Bolt(gh1)
Loading…
↗
14
6GR4515900
Damper
Loading…
↗
