2BMH (1986)
Upper Casing
Diagram: Upper Casing
Parts List
Reference
Description
Price
2
973950603000
Bolt(jf7)
Loading…
↗
3
929900660000
Washer, plain (646)
Loading…
↗
5
932101912300
O-ring (646)
Loading…
↗
6
646146230100
Gasket, exhaust
Loading…
↗
7
6A141137009M
Guide,exhaust
Loading…
↗
8
6A114613A000
Gasket,exhaust 1
Loading…
↗
9
936051506500
Pin, dowel
Loading…
↗
10
973950602500
Bolt
Loading…
↗
13
6464211200EJ
Handle, steering
Loading…
↗
14
646421190200
Grip, steering handle
Loading…
↗
16
929900810000
Ybs67-8 washer, spring
Loading…
↗
17
929900820000
Ybs66-8 washer, plain
Loading…
↗
18
902010911700
Washer 1 6154367300
Loading…
↗
19
953800860000
Nut (661)
Loading…
↗
20
646425910000
Holder, shear pin
Loading…
↗
22
975950655500
Bolt, hexagon w/w deep recess
Loading…
↗
23
929900610000
Washer(6a1)
Loading…
↗
24
6A1451510000
Cover, upper casing
Loading…
↗
25
978900601600
Screw pan head
Loading…
↗
27
6A1451150000
Gasket, upper casing
Loading…
↗
