F6AMH (2003)
VALVE
Diagram: VALVE
Parts List
Reference
Description
Price
1
67D−12111−00
Valve, intake
Loading…
↗
2
67D−12121−00
Valve, exhaust
Loading…
↗
3
68T−12116−00
Seat, valve spring
Loading…
↗
4
68T−12113−00
Spring, valve inne
Loading…
↗
5
7NJ−12117−00
Retainer, valve spring
Loading…
↗
6
7NJ−12118−00
Cotter, valve
Loading…
↗
7
51Y−12119−00
Seal, valve stem
Loading…
↗
8
68T−12146−00
Shaft, rocker
Loading…
↗
9
90387−13M56
Collar (6g8)
Loading…
↗
10
90387−14M03
Collar
Loading…
↗
11
90501−12M40
Spring, compression (6g8)
Loading…
↗
12
68T−12151−00
Arm, valve rocker
Loading…
↗
13
6G8−12159−00
Screw, valve adjusting
Loading…
↗
14
6G8−12158−00
Nut, lock
Loading…
↗
