Yamaha Outboard Parts - VALVE 2 - XF425NSA2 (2019) | Flood Marine

Diagram: VALVE 2

Diagram

Parts List

Reference
Description
Price


1
6GR1217100
Camshaft 1
Loading…

↗
2
6GR1218100
Camshaft 2
Loading…

↗
3
6GR1217200
Camshaft 3
Loading…

↗
4
6GR1218200
Camshaft 4
Loading…

↗
5
6GR115A000
Driven gear assembly
Loading…

↗
6
6GR1156700
Gear, driven 2
Loading…

↗
7
9011910050
Bolt, with washer
Loading…

↗
8
6GR1264500
Pulley assembly 1
Loading…

↗
9
9040112002
Bolt, union
Loading…

↗
10
9310238008
Oil seal
Loading…

↗
11
9458199044
Chain
Loading…

↗
12
6GR1221000
Tensioner assembly, cam chain
Loading…

↗
13
6GR1223000
Tensioner assembly, cam chain 2
Loading…

↗
14
9010506037
Bolt, flange
Loading…

↗
15
6GRW462400
Belt (with rotor bolts)
Loading…

↗
16
6P21159001
Tensioner assembly
Loading…

↗
