LF115B (2024)
ELECTRICAL 4
Diagram: ELECTRICAL 4
Parts List
Reference
Description
Price
1
6EK8231000
Ignition coil assembly
Loading…
↗
2
6EK8231010
Ignition coil assembly
Loading…
↗
3
6EK8237000
Plug cap assembly
Loading…
↗
4
97E9506525
Bolt, hexagon w/w deep recess
Loading…
↗
5
6EK8238800
Plate
Loading…
↗
6
9046406001
Clamp
Loading…
↗
7
9046413227
Clamp
Loading…
↗
8
67F8236100
Clamp, cord
Loading…
↗
9
9046407M41
Clamp(62y)
Loading…
↗
10
67F8236200
Clamp, cord 2
Loading…
↗
11
9011906275
Bolt, with washer
Loading…
↗
12
6EK8196010
Rectifier & regulator assembly
Loading…
↗
13
6EK8197501
Plate, rectifier fitting
Loading…
↗
14
97E9506530
Bolt, hexagon w/w deep recess
Loading…
↗
